20BC043A0AYNANC0 AB PF700变频器

20BC043A0AYNANC0 AB PF700变频器

20BC043A0AYNANC0是PowerFlex 700系列交流驱动器中的变频驱动器。Allen-Bradley是该驱动器的制造公司。驱动器提供了出色的性能，它是易于使用。它的制造是为了在工业环境中提供自动化。

这些变频驱动器用于控制交流电机的转矩。它使用一种不同的算法进行调节和控制。驱动器由400伏交流电供电。电压源由三相电源提供。这个驱动器所需的电流是43安培。20BC043A0AYNANC0驱动器的出厂额定功率输出为22千瓦。驱动器的内部部件被安置在框架3内。驱动器的主体是保形涂层在所有的PowerFlex 700系列。此驱动器中没有配备通信模块。

20BC043A0AYNANC0也被称为零堆叠驱动器。这些驱动器可以彼此相邻安装，而不会降低周围的空气温度。驱动器的独特设计允许访问一个驱动器而不干扰另一个。该驱动器已建立与集成EMC滤波，并配备了CE滤波器和CE扼流圈。驱动器没有人机接口模块。在驱动器的正面，只有一个空白的板盖是目前与公司的标签。在驱动器上安装了IGBT制动系统，用于制动目的。这是一个具有成本效益的解决方案，因为它使用开关再生能源，而不使用外部铜电路。驱动器有24伏直流I/O电压。20BC043A0AYNANC0已获得不同标准驱动认证。它有ABS, CE, C-Tick, RINA等。驱动器来在一个紧凑的尺寸，它很容易安装在一个小的工业设置。

20BC043A0AYNANC0 AB PF700变频器

20BC043A0AYNANC0 is a variable frequency drive in PowerFlex 700 series AC drives. Allen-Bradley is the company that manufactures the drive. The drive offers excellent performance and it is easy to use. It is manufactured to provide automation in an industrial environment.

These variable frequency drivers are used to control the torque of the AC motor. It uses a different algorithm for regulation and control. The drive is powered by 400 volts AC. The voltage source is provided by a three-phase power supply. The current required for this drive is 43 amps. The 20BC043A0AYNANC0 driver has a factory rated power output of 22 kW. The internal components of the drive are housed in frame 3. The body of the drive is conformal coated on all PowerFlex 700 series. There is no communication module in this drive.

20BC043A0AYNANC0 is also known as zero stack drive. These drives can be installed next to each other without reducing the ambient air temperature. The unique design of the drive allows access to one drive without interfering with the other. The driver has been built with integrated EMC filter and is equipped with CE filter and CE choke. The driver has no HMI module. On the front of the drive, only a blank board cover is present with the company label. An IGBT braking system is installed on the drive for braking purposes. This is a cost-effective solution as it uses switching renewable energy without the use of external copper circuitry. The driver has 24 volts DC I/O. 20BC043A0AYNANC0 has obtained driver certifications of different standards. It has ABS, CE, C-Tick, RINA and so on. The drive comes in a compact size and it is easy to install in a small industrial setup.

20BC043A0AYNANC0 AB PF700变频器
