1771-OX 是一款电源触点输出模块

1771-OX 是一款电源触点输出模块

艾伦-布拉德利 1771-OX 是一款电源触点输出模块。该模块有 4 个常开/常闭输出点可用。该模块有四个状态指示器，每个输出 1 个指示器。这些指示器表示输出继电器线圈通电或断电的状态。1771-OX 还具有一个保险丝，可作为过载情况的保护。如果过载，输出电路将被打开。

1771-OX 模块的额定电压为 0-250V AC RMS 和 0-175V DC。它的最大额定电流为 2 A，额定功率为 200 VA。该模块存在浪涌电流，这些电流是 5.5A AC 峰值持续 5 秒、6A DC 持续 500 秒和 15A DC 持续 500 毫秒。请注意，浪涌电流每 10 秒可重复一次。该模块的最大导通状态接触电阻为0.25 Ω，最大背板电流为550 mA，隔离电压为2500V AC RMS。

其功耗范围为最小 10.2 W 至最大 6.2 W。该模块的散热范围从最小 9.8 BTU/小时到最大 9.9 BTU/小时不等。

1771-OX 是一款电源触点输出模块

The Allen-Bradley 1771-OX is a power contact output module. The module has 4 normally open/normally closed output points available. The module has four status indicators, each output 1 indicator. These indicators indicate whether the output relay coil is powered on or off. The 1771-OX also has a fuse that acts as protection in case of overload. If overloaded, the output circuit will be turned on.

The 1771-OX module is rated for 0-250V AC RMS and 0-175V DC. It has A maximum rated current of 2 A and a rated power of 200 VA. The module has surge currents, which are 5.5A AC peaks lasting 5 seconds, 6A DC peaks lasting 500 seconds, and 15A DC peaks lasting 500 milliseconds. Please note that the surge current can be repeated every 10 seconds. The module has a maximum on-state contact resistance of 0.25Ω, a maximum backplane current of 550 mA, and an isolation voltage of 2500V AC RMS.

Power consumption ranges from a minimum of 10.2W to a maximum of 6.2W. The module's heat dissipation ranges from a minimum of 9.8 BTU/ hour to a maximum of 9.9 BTU/ hour.

1771-OX 是一款电源触点输出模块
