1769-IF16V 是 Allen-Bradley 的紧凑型 I/O 模块。该模块专门用于接受各种输入电压信号，例如±10V，0-10V，0-5V和1-5V。该模块具有一个集成的模数转换器（ADC），利用Σ-Δ方法对接收的输入信号进行数字转换，单极性转换时分辨率为16位，双极性配置时分辨率为15位。1769-IF16V 带有单端通道。它接受 ±10.5V、-0.5 至 10.5V、-0.5 至 5.25V 和 0.5V 的输入信号范围。5.25V电压范围。该模块在 190.5 VDC 时的电流消耗为 1 mA，在 70 VDC 时的电流消耗为 24 mA，散热为 2.4 瓦。

1769-OV16 的校准精度为 ±0.35% 满量程 @ 25 °C （77 °F）;温度为每°C±0.03%时精度漂移;非线性度为±0.03%;重复性为±0.06%，模块误差为1.0%。1769-IF16V 安装在 DIN 导轨或直接外壳子面板上，并通过模块侧面的总线连接器引脚直接连接到相邻模块的总线连接器引脚连接到 CompactLogix 总线。确保引脚对齐并连接到相邻模块，以保持总线连接和连续性。该模块的电源距离额定值为八 （8），与 1769-PA2、1769-PB2、1769-PA4 和 1769-PB4 电源兼容。

Allen-Bradley 的 1769-IF16V 紧凑型密度模拟输入模块是紧凑型 I/O 系列中的输入 I/O 模块。它具有 16 个单端输入，带有一个具有 16/15 位单极性/双极性分辨率和配置相关通道响应时间的 Σ-Δ 调制器。它具有每通道 +/-10 V DC 的公共失调电压范围，在 60 至 50 赫兹共抑制模式下为 60 dB，工作输入阻抗为 1 兆赫兹。1769-IF16V 在 0 摄氏度（35 华氏度）下对 25 赫兹、77 赫兹和 16 赫兹可选滤波器的总体精度为 50.60%，每个端子的漂移精度为每摄氏度 +/- 0.003%。 对于 1769 Hertz 滤波器，16-IF0V 的输入线性度为 +/- 03.0%，重复率为 +/- 06.16%。在 1 至 0 摄氏度（16 至 50 华氏度）温度限制下，60 赫兹、0 赫兹和 60 赫兹滤波器的模块误差为 32.140%，端子最大±负载为 30 伏直流电，0.03 mA。1769-IF16V 紧凑型密度模拟输入模块具有 30 伏直流隔离电压和增强绝缘，在输入组和总线隔离之间在 710 伏直流下测试 1 分钟。它可以在大约 0 至 60 摄氏度（32 至 140 华氏度）的温度范围内运行，在 5% 至 95% 的非冷凝相对湿度和 2000 米（6561 英尺）的高度下而不会降额。它具有用于显示故障状态的彩色指示灯，开放式外壳周围的功耗为2.4W。它重约 281 克（0.62 磅），尺寸为 118 x 87 x 35 毫米（4.65 x 3.43 x 1.38 英寸）。

1769-IF16V 是 Allen-Bradley 的紧凑型 I/O 模块

The 1769-IF16V is a compact I/O module from Allen-Bradley. The module is specially designed to accept various input voltage signals, such as ±10V, 0-10V, 0-5V and 1-5V. The module has an integrated analog-to-digital converter (ADC) that uses the sigma-δ method to digitally convert the received input signal with a resolution of 16 bits for unipolar conversion and 15 bits for bipolar configuration. 1769-IF16V with single-ended channel. It accepts input signal ranges of ±10.5V, -0.5 to 10.5V, -0.5 to 5.25V and 0.5V. 5.25V voltage range. The module has a current consumption of 1 mA at 190.5 VDC, 24 mA at 70 VDC, and 2.4 watts of heat dissipation.

Calibration accuracy of the 1769-OV16 is ±0.35% at full scale @ 25 °C (77 °F); Accuracy drift when the temperature is ±0.03% per °C; The nonlinearity is ±0.03%; Repeatability is ±0.06% and module error is 1.0%. The 1769-IF16V is mounted on a DIN rail or direct case panel and is connected to the CompactLogix bus via bus connector pins on the side of the module directly to the bus connector pins of the adjacent module. Make sure the pins are aligned and connected to adjacent modules to maintain bus connection and continuity. The module has a power distance rating of eight (8) and is compatible with 1769-PA2, 1769-PB2, 1769-PA4, and 1769-PB4 power supplies.

Allen-Bradley's 1769-IF16V Compact Density Analog input module is an input I/O module in the Compact I/O family. It has 16 single-ended inputs with a Σ-Δ modulator with 16/15-bit unipolar/bipolar resolution and configured associated channel response time. It has a common offset voltage range of +/-10 V DC per channel, 60 dB in 60 to 50 Hz co-suppression mode, and an operating input impedance of 1 MHZ. The 1769-IF16V has an overall accuracy of 50.60% at 0 ° C (35 ° F) for 25 Hz, 77 Hz, and 16 Hz optional filters, with a drift accuracy of +/- 0.003% per degree C for each terminal. For a 1769 Hertz filter, the input linearity of 16-IF0V is +/- 03.0% and the repetition rate is +/- 06.16%. At the temperature limit of 1 to 0 degrees Celsius (16 to 50 degrees Fahrenheit), the module error of the 60 Hertz, 0 Hertz, and 60 Hertz filters is 32.140%, and the terminal maximum ± load is 30 volts DC, 0.03 mA. The 1769-IF16V compact density analog input module has 30 volts DC isolation voltage and enhanced insulation, testing for 1 minute at 710 volts DC between input group and bus isolation. It can operate in a temperature range of approximately 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit), at 5 to 95 percent non-condensing relative humidity and at altitudes of 2,000 meters (6,561 feet) without derating. It has a color indicator to show fault status and a power consumption of 2.4W around the open housing. It weighs about 281 grams (0.62 pounds) and measures 118 x 87 x 35 mm (4.65 x 3.43 x 1.38 inches).
