在紧密纺细纱机的控制系统，采用了三套伺服驱动系统和无刷伺服电机，分别控制前、后罗拉以及钢领板；采用1台变频器控制主传动电机，采用1台变频器控制风机；整个系统采用邦纳SHP一体式控制器进行控制和监控，SHP一体式控制器与变频器及伺服间采用高速CANopen总线进行通讯，同时采用SHP集成的触摸屏进行系统操作和监控。

控制要点：

1． 可编程控制器：由邦纳SHP一体式控制器实现整机的逻辑控制和参数计算，实现整机的 优控制。 SHP控制器是与传统的控制产品不同， 的邦纳SHP控制器可以同时完成PLC和触摸屏的功能，集成I/O和网络接口人机界面， 大大低于同性能PLC与人机界面组合，此款设备包括控制器，人机界面，内置I/O，网络和可移动的大容量数据存储器，成为一个一体化单元，是一款功能强大，可信赖的控制产品，画面和控制程序用同一个工业级软件BAPS完成。由SHP一体式集成的触摸屏实现纺纱参数的设定、显示和故障监控。

In the control system of compact spinning frame, three sets of servo drive system and brushless servo motor are used to control the front roller, the back roller and the steel collar plate respectively. One frequency converter is used to control the main drive motor, and one frequency converter is used to control the fan. The whole system uses Bonner SHP integrated controller to control and monitor, SHP integrated controller and inverter and servo using high-speed CANopen bus communication, while SHP integrated touch screen for system operation and monitoring.

Control points:

1. Programmable controller: The Bonner SHP integrated controller realizes the logic control and parameter calculation of the whole machine, and realizes the optimal control of the whole machine. SHP controller is different from traditional control products, the Bonner SHP controller can complete the functions of PLC and touch screen at the same time, integrated I/O and network interface man-machine interface, much lower than the same performance PLC and man-machine interface combination, this device includes controller, man-machine interface, built-in I/O, network and removable large-capacity data memory, Become an all-in-one unit, is a powerful and reliable control product, the screen and the control program using the same industrial grade software BAPS. The SHP integrated touch screen realizes the setting, display and fault monitoring of spinning parameters.
