3500/22M瞬态数据接口（TDI）是接口3500监控系统和兼容软件（System 1状态监测和诊断软件和3500系统配置

软件）。TDI公司结合3500/20机架接口模块的功能（RIM）具有通信的数据收集能力处理器，如TDXnet。TDI位于

3500机架。它与M系列监视器（3500/40M，3500/42M等），以连续采集稳态和瞬态动态（波形）数据并传递该

数据通过以太网链路连接到主机软件。请参阅有关更多信息，请参阅本文档末尾的兼容性部分信息静态数据捕获功

能是TDI的标准功能。然而，使用可选的通道启用磁盘将允许TDI捕捉动态和高分辨率瞬态数据。TDI包含通信3500

机架内的处理器功能。尽管TDI提供了一些与整个机架，它不是关键监控路径的一部分，并且对整体的正常运行没有

影响自动机械保护监控系统。每一个3500机架需要一个TDI或RIM，它们总是占用插槽1（靠近电源）。

1.主模块

2.10 Base-T/100 Base-TX（铜）以太网I/O模块

3.100 Base-FX（光纤）以太网I/O模块

4.LED指示模块的工作状态

5.硬件开关

6.用于配置或检索机械数据的USB配置端口

7.OK Relay（正常继电器）指示整个机架的OK（正常）状态

8.信号公共外部接地端子

9.用于配置和数据采集的RJ-45以太网端口

10.系统触点

11.用于配置和数据采集的光纤以太网端口
