136711-01 BENTLY 带内部屏障和内部终端 I/O模块

136711-01 BENTLY 带内部屏障和内部终端 I/O模块

3500/50M转速表模块是一个2通道模块它接受来自接近探测器或磁性探测器的输入皮卡来确定轴的转速，转子加速度，或转子方向。这个模块比较了这些根据用户可编程报警设定值进行测量并在违反设定值时产生警报。转速表模块使用3500机架编程配置软件。以下配置选项是可用的:

速度监控，设定值报警和速度带令人担忧的速度监控，设定值报警和零速度通知转速监控，设定值报警和转子惊人的加速度速度监控，设定值报警和反转旋转的通知

3500/50M转速表模块可以配置为的背板提供条件键相量信号3500机架，供其他显示器使用。因此，你不需要机架上需要一个单独的Keyphasor模块。

3500/50M转速表模块具有峰值保持功能存储最高速度，最高倒车速度，或者机器反向旋转的次数达成。您可以重新设置峰值。

考虑以下准则和下单前限制:

l外部终止块不能用于内部终止I/O模块。

l当订购I/O模块与外部终止，必须订购外部终止端子块和电缆分开。

l使用总线外部终止块只有TMR I/O模块。

136711-01 BENTLY 带内部屏障和内部终端 I/O模块

The 3500/50M tachometer module is a 2-channel module that accepts input from a pickup truck near a detector or magnetic detector to determine the shaft speed, rotor acceleration, or rotor direction. This module compares these measurements based on user programmable alarm setpoints and generates alerts when setpoints are violated. The tachometer module uses 3500 rack programming configuration software. The following configuration options are available:

Speed monitoring, set point alarm and speed belt alarming speed monitoring, set point alarm and zero speed notification speed monitoring, set point alarm and rotor alarming acceleration speed monitoring, set point alarm and reverse rotation notification

The 3500/50M tachometer module can be configured as a backplane to provide a conditional key phasor signal 3500 rack for use by other displays. Therefore, you do not need a separate Keyphasor module on the rack.

The 3500/50M tachometer module has a peak-hold function to store maximum speed, maximum reverse speed, or the number of times the machine has rotated in reverse. You can reset the peak value.

Consider the following guidelines and pre-order restrictions:

An external termination block cannot be used to internally terminate an I/O module.

When ordering an I/O module with an external termination, the external termination terminal block must be ordered separately from the cable.

l Only TMR I/O modules use bus external termination blocks.
