3500/33-01-00 框架仪表系统振动监测继电器模块

3500/33-01-00 框架仪表系统振动监测继电器模块

3500/33-01-00继电器模块是一个全高度的16通道模块，它可提供16个继电器的输出量。任何数量的16通道继电器模块，都可放置在框架接口模块右边的任一个槽位里。16通道继电器模块的每个输出，都可以独立编程，以执行所需要的表决逻辑。

本特利3500/33继电器模块升级后的前面板、I/O接线后面板分别为：

149986-01  备用16通道继电器控制模块

149992-01  备用16通道继电器输出模块

本特利3500/33每个继电器模块上的继电器，都具有“报警驱动逻辑”。该报警驱动逻辑可用“与门”和“或门”逻辑编程，并可利用框架中的任何监测器通道或任何监测器通道的组合所提供的报警输入(警告或危险)。该报警驱动逻辑应用框架组态软件编程，可满足应用中的特殊需要。

3500/33-01-00 框架仪表系统振动监测继电器模块

The 3500/33-01-00 relay module is a full-height 16-channel module that provides the output of 16 relays. Any number of 16-channel relay modules can be placed in any slot on the right of the frame interface module. Each output of the 16-channel relay module can be programmed independently to perform the required voting logic.

Bentley 3500/33 relay module after the upgrade of the front panel, I/O wiring rear panel are:

149986-01 Standby 16-channel relay control module

149992-01 Spare 16-channel relay output module

The Bentley 3500/33 relays on each relay module have "alarm drive logic". The alarm driver logic can be programmed with and Gate and or Gate logic and can take advantage of the alarm inputs (warning or danger) provided by any monitor channel in the frame or a combination of any monitor channel. The alarm driver logic application framework configuration software programming can meet the special needs of applications.
