BENTLY 3500/42M 176449-02 前置器地震监测器为四通道

BENTLY 3500/42M 176449-02 前置器地震监测器为四通道

3500/42M前置器地震监测器：  l通过不断比较来保护机器  BENTLY 3500/42M 176449-02 根据配置的警报监测参数  驱动警报的设置点。  l向双方传达重要的机器信息  操作和维护人员。

3500/42M前置器地震监测器为四通道  接受近距离和地震输入的监测器  传感器。它调节信号以提供振动和  位置测量并比较条件  带有用户可编程报警的信号。

您可以使用3500机架对每个通道进行编程  监控和报告的配置软件：  -径向振动-REBAM-推力  BENTLY 3500/42M 176449-02 位置  -加速度-胀差-轴  完全的  -偏心度-圆形验收  区域-速度  OK发光二极管  指示何时  3500/42M前置器  地震监测器  操作正常。  发送/接收LED  指示何时  3500/42M前置器  地震监测器  与…沟通  3500中的其他模块  支架  旁路LED  指示何时  3500/42M前置器  地震监测器处于  旁路模式。  缓冲的  传感器  输出  每个显示器的前部  有一个同轴连接器  对于每个通道。  每个连接器都有短路保护。  输出  阻抗550Ω  传感器  电源-24 Vdc  录音机  +4至+20毫安  数值与  监视器满刻度。  显示器提供  单个记录器值  对于每个通道。  监视器操作  不受短路影响  记录器上的电路  输出。  电压  顺从  （电流输出）  0至+12 Vdc范围

BENTLY 3500/42M 176449-02 前置器地震监测器为四通道

3500/42M preprocessor seismic monitor: l Protects the machine by constant comparison BENTLY 3500/42M 176449-02 Drives the setting point of the alarm according to the configured alarm monitoring parameters. l Communicate important machine information to both operators and maintenance personnel.

The 3500/42M preprocessor seismic monitor is a four-channel monitor sensor that accepts proximity and seismic inputs. It adjusts signals to provide vibration and position measurements and compares conditions with signals with user programmable alarms.

You can use configuration software with 3500 racks to programmatically monitor and report on each channel: - Radial Vibration -REBAM- Thrust BENTLY 3500/42M 176449-02 Position - Acceleration - differential expansion - shaft complete - eccentricity - Circular acceptance area - Speed OK LED indicates when 3500/42M preprocessor seismic monitor The operation is normal. Send/receive LED indicating when 3500/42M preprocessor earthquake monitor communicates with... The other module bracket bypass leds in the Communication 3500 indicate when the 3500/42m preprocessor seismic monitor is in bypass mode. Buffered sensor output The front of each display has a coaxial connector for each channel. Each connector has short circuit protection. Output impedance 550Ω sensor power supply -24 Vdc recorder +4 to +20 mA values with monitor full scale. The display provides a single logger value for each channel. Monitor operation is not affected by short circuit on the recorder circuit output. Voltage compliance (current output) range 0 to +12 Vdc
