3500/64M动态压力监测器是一个单槽， 四通道监测器，从高温接受输入压力传感器，并使用此输入来驱动警报。的监视器每个通道的-一个测量变量是带通动态压力。

您可以使用3500机架配置软件进行以下操作配置带通角频率与-一个附加陷波滤波器。监视器提供一个记录器输出控制系统的应用。

主要用途为3500/64M动压

监视器是提供以下内容:

|连续比对保护机器根据配置的告警监控参数驱动警报的设定值

操作所需的基本机器信息维修人员

每个通道，根据配置，限制其输入信号产生的各种参数称为被测变量。您可以配置警报和危险设定值每个活跃的测量变量。

低和高过滤模式是选项通道。通道1和通道2形成一对，并且通道3和4是另一对。 你可能在每个上选择不同的带通选项通道对的通道。然而，渠道在对内操作必须相同过滤模式。

您可以设置信号处理，以便监视器只提供通道1输入到所有四个频道。这个特性被称为级联模式，在3500中表示为1 >ALL机架配置软件。

在“级联模式”可以选择过滤模式仅用于通道对的选项。一个传感器提供四个不同通道的输入过滤要求。 因此，你可以配置四个单独的带通滤波器选项还有四个独立的全尺寸量程，其中-个传感器输入。

这两种过滤方式提供的不同过滤的质量。
