3500/05-01-03-00-00-00 系统机架 绕过所有其他配置的通道

特征：

可容纳所有 3500 显示器模块和机架电源

制造有 （2） 种尺寸：全尺寸机架和迷你机架

以 （3） 格式制造：面板安装、机架安装和穿板式安装

7 或 14 个机架位置

本特利 Nevada 3500/05 系统机架设计可容纳所有 3500 显示器模块和机架电源 用品。它允许各种 3500 模块相互通信 以及根据需要为每个模块分配电源的电源。

3500 机架有两种尺寸：

1. 全尺寸机架：19 英寸 EIA 机架，带 14 个可用模块插槽

2.迷你机架：12 英寸机架，带 7 个可用模块插槽

3500 机架以三种格式制造：

1. 面板安装：这种机架格式安装到矩形切口上 面板，并使用机架随附的夹子固定到面板上。 接线连接和 I/O 模块可从 架。

2. 机架安装：此机架格式将 3500 机架安装在 19 英寸 EIA 上 rails 的 Rails 中。接线连接和 I/O 模块可从侧面访问 的机架。

3. 隔板安装：这种机架格式将机架安装在墙上或 面板。布线 连接和 I/O 模块可从机架前部访问。 3500/05 Mini-Rack 不提供此格式。

3500/05-01-03-00-00-00 系统机架 绕过所有其他配置的通道

Features:

Can accommodate all 3500 display modules and rack power supply

Manufactured in (2) sizes: full size rack and mini rack

Manufactured in (3) format: panel mount, rack mount and through-plate mount

7 or 14 rack positions

The Bentley Nevada 3500/05 system rack is designed to accommodate all 3500 display modules and rack power supplies. It allows various 3500 modules to communicate with each other as well as a power supply that allocates power to each module as needed.

The 3500 rack is available in two sizes:

1. Full-size rack: 19-inch EIA rack with 14 available module slots

2. Mini rack: 12-inch rack with 7 available module slots

3500 racks are manufactured in three formats:

1. Panel mounting: This rack format is mounted to the rectangular cut upper panel and secured to the panel using the clamp that comes with the rack. Wiring connections and I/O modules are available from the rack.

2. Rack Mount: This rack format mounts 3500 racks in rails on 19-inch EIA Rails. Wiring connections and I/O modules can be accessed from the side of the rack.

3. Partition mounting: This rack format mounts the rack on a wall or panel. Cabling connections and I/O modules are accessible from the front of the rack. This format is not available in 3500/05 Mini-Rack.
