3500/05-01-02-00-00-01 3500/05系统机架 绕过所有其他配置的通道制造商:本特利内华达产品编号:3500/05-01-02-00-00
产品详情
制造商:本特利内华达
产品编号:3500/05-01-02-00-00-01
产品型号:3500/05系统机架
美国制造
机架尺寸:01 = 19英寸机架(14个模块插槽)
安装选项:02 =机架安装选项,全尺寸机架(安装到19英寸EIA机架)
代理审批选项:00 =无
保留:00 =无
欧洲合规选项:01 = CE
尺寸(长x宽x高):48.26厘米x 34.92cm厘米x 26.59cm厘米
装运重量:4.5千克
3500/05-01-01-00-00-00测试OK极限的一般方法是输入直流电压并进行调整高于OK上限且低于OK下限。此电压将导致非OK状态,OK继电器改变状态(断电)。鞋面和OK下限显示在测试的Verification(验证)屏幕中计算机
1.从上的通道端子断开PWR、COM/-和SIG/+现场接线超速检测输入/输出模块。
2.按照第5.1.5.1节(测试设备和软件设置-超速检测系统)。
3.绕过所有其他配置的通道。
4.将电源电压调整至-10.00 Vdc。
5.通过短路上的复位触点来复位超速检测模块超速输入/输出模块或启用通道复位软件开关。验证监视器OK指示灯亮起,并且Verification(验证)屏幕的Channel Status(通道状态)组显示OK(正常)。
Manufacturer: Bentley, Nevada
Product Number :3500/05-01-02-00-00-01
Product Model :3500/05 System rack
Made in the USA
Rack Size :01 = 19 inch rack (14 module slots)
Mounting options :02 = Rack mounting options, full size rack (mounted to 19-inch EIA rack)
Agent approval option :00 = None
Reserved :00 = none
European Compliance option :01 = CE
Dimensions (L x W x H):48.26 cm x 34.92cm x 26.59cm
Shipping weight :4.5 kg
3500/05-01-01-00-00-00 The general method of testing the OK limit is to input the DC voltage and adjust it above the upper OK limit and below the lower OK limit. This voltage will cause a non-OK state and the OK relay will change state (power off). The upper and OK lower limit are displayed on the test computer in the Verification screen
1. Disconnect the PWR, COM/-, and SIG/+ input/output modules from the upper channel terminals.
2. Follow Section 5.1.5.1 (Test Equipment and Software Setup - Overspeed Detection System).
3. Bypass all other configured channels.
4. Adjust the power supply voltage to -10.00 Vdc.
5. Restore the overspeed input/output module of the overspeed detection module or enable the channel reset software switch through the reset contact on the short circuit. The Verification monitor OK indicator lights up, and the Channel Status group on the Verification screen shows OK.
