1900/65A 167699-02|1900/65A通用设备监视器

1900/65A 167699-02|1900/65A通用设备监视器

24 位 ADC 转换

四个振动/位置/速度输入

四个温度输入

可配置的比例因子和满量程范围

内部 OK 检查和状态

独立的警报和危险设定点

200 个参赛项目列表

6 个继电器输出

继电器操作是可编程的

每个传感器通道的缓冲输出

四个可配置的 4-20 mA 记录仪输出

1900/65A通用设备监视器旨在持续监控和保护各种应用和行业中使用的设备。该监视器的低成本使其成为通用机器和过程的理想解决方案，可以从持续监控和保护中受益。

输入

1900/65A提供4个传感器输入和4个温度输入。软件可以配置每个传感器输入，以支持2线和3线加速度计，速度传感器或接近传感器。每个温度输入支持E、J、K和T型热电偶，以及2线或3线rtd。

输出

1900/65A提供6个继电器输出，4个4-20 mA记录仪输出和一个专用缓冲输出。用户可以使用1900配置软件配置继电器触点打开或关闭根据OK，警报和危险状态的任何通道或通道的组合，并提供数据从任何通道上的任何变量的任何记录器输出。专用缓冲输出可以为每个换能器输入提供信号。

Modbus网关选项允许监视器直接向任何Modbus客户端提供静态变量、状态、事件列表、时间和日期信息，包括分布式控制系统(dcs)、监控和数据采集(SCADA)系统、可编程逻辑控制器(plc)或System 1软件。监视器使用内部计数器和Modbus客户端/主时间引用来生成时间和日期信息。用户可以通过订购1900/01通信升级(参见订购信息部分)来升级没有Modbus网关的监视器。1900/65A支持通过以太网和软件可配置的RS232/485串口进行Modbus通信。

1900/65A 167699-02|1900/65A通用设备监视器

24-bit ADC conversion

Four vibration/position/speed inputs

Four temperature inputs

Configurable scale factors and full scale ranges

Internal OK check and status

Independent alarm and danger set points

List of 200 entries

6 relay outputs

Relay operation is programmable

Buffer output for each sensor channel

Four configurable 4-20 mA recorder outputs

The 1900/65A Universal Device Monitor is designed to continuously monitor and protect equipment used in a variety of applications and industries. The low cost of this monitor makes it an ideal solution for general-purpose machines and processes that can benefit from continuous monitoring and protection.

input

The 1900/65A offers 4 sensor inputs and 4 temperature inputs. The software can configure each sensor input to support 2-wire and 3-wire accelerometers, speed sensors, or proximity sensors. Each temperature input supports type E, J, K, and T thermocouples, as well as 2-wire or 3-wire RTDS.

exportation

The 1900/65A offers six relay outputs, four 4-20 mA recorder outputs, and a dedicated buffer output. Users can use the 1900 configuration software to configure relay contacts to open or close any channel or combination of channels according to OK, alarm and danger states, and to provide data from any logger output on any variable on any channel. A dedicated buffer output can provide a signal for each transducer input.

The Modbus Gateway option allows the monitor to provide static variables, status, event lists, time and date information directly to any Modbus client, including distributed control systems (dcs), supervisory control and Data acquisition (SCADA) systems, programmable logic controllers (PLCS), or System 1 software. The monitor uses internal counters and Modbus client/master time references to generate time and date information. Users can upgrade monitors without Modbus gateways by ordering the 1900/01 Communications upgrade (see Ordering Information section). The 1900/65A supports Modbus communication over Ethernet and a software-configurable RS232/485 serial port.
